Full Seed Ahead
When time's short and there's plenty of ground to cover, know you can seed with confidence. John Deere offers a complete line of everything you need—in the sizes you want—to seed for success. From air drills and air carts to fertilizer attachments and box drills, that all includes the precision ag technology to help you maximize your productivity so you can seed smart with accuracy you can measure.
The New John Deere C-Series Air Carts
Simple. Concise. Innovative.
- Seed up to eight times1 more precisely with the new AccuRate™ stainless steel electric meters
- Industry-exclusive EZCal™ system that saves time and steps by sending calibration numbers automatically to the cab display
- Calibrate from the cab with ActiveCal and improve seeding confidence and productivity with tank scales
- Fully integrated, intelligent plug-and-play seeding solution
Bigger. Better. Smarter.
The XL Air Carts from John Deere
More capacity means less tendering—and less tendering means you can finish faster. That's why we're building even bigger air carts. More capacity but still packed with John Deere Precision to help you seed more acres, more accurately, and more efficiently.
Go big with the new C1450T, with five tanks and a rated capacity of 1,460 bu (51,499 L). The C1100T gives you a capacity of 1,120 bu (39,468 L) and, like the C1450T, a 105 bu (3,700 L) Flex Tank for even greater versatility. And the C850T offers 850 bu (29,953 L) capacity, a bit smaller than its two big brothers, but still large enough to handle large seed loads all day long.
EZLift System
The C1100T and C1450T feature an EZLift System that allows you to load bulk bags directly into tanks 1, 2, and 3. The hydraulically powered arm can lift up to 1,088 kg (2,400 lb), and a large storage platform can hold an extra bulk bag or seed pallet.
- Eliminates the need for additional tractors, picker trucks, or telehandlers in the field, reducing field logistics.
- Direct bulk bag unloading speeds up refilling and enhance uptime.
- On-cart side storage platform keeps an extra bulk bag or pallet of seed within reach, ensuring uninterrupted tendering.
- Streamlines tendering in time-sensitive windows, helping you stay productive when every minute counts.
New 105-bu Flex Tank
A new 105-bu (3,700.1-L) Flex Tank provides space for 55 more bushels (1,938.2 more liters) than previous models, giving you more versatility in your tank mixes. Instead of using your Flex Tank for just canola or inoculant, you can fill it with extra fertilizer, wheat, and more. Lower and upper fill locations make it easy to empty bags. And a new platform – when used with the EZLift System – allows you to untie an extra seed bag between your waist and shoulder.
New, Wider Conveyor with Stainless Steel Hopper
We made the conveyors on the C1100T and C1450T wider – 30.5 and 40.6 centimeters (12 and 16 inch) respectively. This gives them a lower angle of repose for higher fill rates. Plus, stainless steel hoppers add extra corrosion resistance.
C-Series Tank Scales
Boost your seeding confidence with tank scales – now available on all C-Series Air Carts. Individual scales positioned on each tank tell you how many acres you have left until empty. With the G5e Cart Side Display, you can view tank scale data and pressures while you fill product. Plus, with ActiveCal, you can recalibrate any time while seeding from the cab.
RelativeFlow™ Blockage Sensors
Enjoy peace of mind knowing seed is being distributed accurately. RelativeFlow™ Blockage Sensors help ensure uniform distribution, and are now available on all air seeding tools.
- Get alerts when blockages or reductions occur.
- Avoid the hassles and costs of reseeding because of run blockages, or retaining seed and fertilizer.
- Save time by not having to leave the tractor to check for blockages.
Quick Change Blade (ProSeries™ Enhancement)
Change blades faster to save time, and reduce labour costs. Quick Change Blades are available on all no-till air seeding tools.
- Replace blades easily before, during, or after seeding season.
- Reduce change time by up to 45%1.
- Minimize labour needed for manual blade changes.
TruSet™ In-Cab Downforce
Be confident in your seed and fertilizer placement as you control downforce without ever having to leave the cab. You can view and adjust downforce settings on your generation 4 display.
- Improve seed-to-soil contact.
- Achieve uniform emergence across varying soil conditions.
- Reduce downtime by not leaving the cab to adjust downforce manually.
Fast and Easy Calibrations
EZCal™ makes calibration fast and easy, and helps you:
- Reduce operator error and shorten the learning curve for new operators.
- Eliminate the need for calibration bags and save more than 100 walking steps.3
Plus, tank scales with ActiveCal™ allow calibration from your cab, so you can:
- Monitor individual tank weight.
- Maximize productivity by knowing how much product remains in the tank and when to refill.
Stainless Steel Electric Meters
AccuRate™ individually controlled stainless steel electric meters are corrosion-resistant, reduce maintenance costs, and provide the following benefits
- Higher-Resolution Prescriptions: Adjust the speed and volume of product at a primary level by controlling the meter, allowing up to 8x more precision.4
- Curve Compensation: Adjusts meter rates to match tool speed on the inside and outside of a turn, ensuring the applied product rate remains consistent across the tool.
- SectionCommand™ Pro: Shuts off each meter individually instead of using gates, preventing potential seed damage and eliminating seed dumping.
ProSeries™ Opener Aftermarket Parts
Improve seed-to-soil contact, depth consistency, germination and uniform emergence with ProSeries™ Opener
Go from good to great with the ProSeries™ Opener Aftermarket Parts from John Deere. Upgrade your 90 Series Opener with six state-of-the-art parts to improve seed-to-soil contact, depth consistency, germination and uniform emergence.
Seeding Technology
TruSet™ Technology
Adjust depth and down-pressure in seconds from your cab
RelativeFlow Blockage System
Spot potential problems before they occur
Air Hoe and No-Till Air Drills
Legendary John Deere iron that's designed to help you seed faster and more accurately from the first pass to the last.
Integrated Tank Air Drills
Enhancements to the Quick Change Blade of our ProSeries™ Openers, allow you to reduce change time by up to 45%.4 Choose from a variety of working widths and row spacing.
Box Drills
Whether you choose the 455 Front-Folding Grain Drill or the 1590 No-Till Drill, you'll get the reliability and performance you expect from John Deere.
Compare Our C-Series Air Carts
| Model | Capacity | Pull Type |
|---|---|---|
|
12.3 cu m (350 bu.) |
Leading |
|
|
14.1 cu m (400 bu.) |
Leading |
|
|
17.6 cu m (500 bu.) |
Leading |
|
|
19.4 cu m (550 bu.) |
Leading |
|
|
22.9 cu m (650 bu.) |
Leading |
| Model | Capacity | Pull Type |
|---|---|---|
|
12.3 cu m (350 bu.) |
Trailing |
|
|
14.1 cu m (400 bu.) |
Trailing |
|
|
17.6 cu m (500 bu.) |
Trailing |
|
|
19.4 cu m (550 bu.) |
Trailing |
|
|
22.9 cu m (650 bu.) |
Trailing |
|
|
29.9 cu m (850 bu.) |
Trailing |
|
|
38.7 cu m (1120 bu.) |
Trailing |
|
|
51.4 cu m (1460 bu.) |
Trailing |
Compare our Air Drills
| Model | Working Width | Transport Width | Fertilizer Placement | Opener | Row Spacing |
|---|---|---|---|---|---|
|
40 ft., 41 ft. 8 in. |
20 ft. |
In Furrow |
Ground-engaging knife |
7.5 in. (19.05-cm) |
|
|
50 ft., 50 ft. 7.5 in. |
20 ft. |
In Furrow |
Ground-engaging knife |
7.5 in. (19.05-cm) |
|
|
59 ft. 4 in., 61 ft. 7 in., 62 ft. 3 in |
20 ft. |
In Furrow |
Ground-engaging knife |
7.5 in. (19.05-cm) |
|
|
41 ft. 8 in., 50 ft. 8 in. |
20 ft. |
Separate |
Ground-engaging knife |
10-in. (25.4-cm) |
|
|
41 ft. 8 in., 50 ft. 8 in. |
20 ft. |
Separate |
Ground-engaging knife |
10-in. (25.4-cm) |
|
|
58 ft. 4 in., 60 ft. |
20 ft. |
Separate |
Ground-engaging knife |
10-in. (25.4-cm) |
|
|
30 ft. |
14 ft. 4 in., 18 ft. 4 in. |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
36 ft. |
14 ft. 4 in., 18 ft. 4 in., |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
40 ft. |
14 ft. 4 in., 18 ft. 4 in., |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
42 ft. |
14 ft. 4 in., 18 ft. 4 in., |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
50 ft. |
14 ft. 4 in., 18 ft. 4 in., |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
60 ft. |
14 ft. 4 in., 18 ft. 4 in., |
In Furrow |
New ProSeries™ |
7.5-in. (19.05-cm) |
|
|
30 ft. |
14 ft. 4 in., 18 ft. 4 in. |
Separate |
New ProSeries™ |
10-in. (25.4-cm) |
|
|
40 ft. |
14 ft. 4 in., 18 ft. 4 in. |
Separate |
New ProSeries™ |
10-in. (254-mm) |
|
|
43 ft. |
14 ft. 4 in., 18 ft. 4 in. |
Separate |
New ProSeries™ |
10-in. (25.4-cm) |
|
|
60 ft. |
14 ft. 4 in., 18 ft. 4 in. |
Separate |
New ProSeries™ |
10-in. (25.4-cm) |
|
|
40 ft. |
19 ft., 22.6 ft |
In Furrow |
Air Hoe Drill |
9-in. (23-cm) paired row |
|
|
56 ft. |
19 ft., 22.6 ft |
In Furrow |
Air Hoe Drill |
9-in. (23-cm) paired row |
|
|
28 ft., 36 ft., 44 ft. |
16 ft. 3 in., 19 ft. |
In Furrow |
Double-disk openers |
6 in. (15-cm) |
|
|
60ft. |
20 ft. 8 in. |
Separate |
Ground engaging dual knife |
10-in. (25.4 cm) 12-in. (30.48 cm) |
|
|
70 ft. |
19 ft. 10 in. |
Separate |
Ground-engaging dual knife |
10-in. (25.4 cm) 12-in. (30.48 cm) |
|
|
80 ft. |
25 ft. 4 in. |
Separate |
Ground-engaging dual knife |
12-in. (30.48 cm) |
|
|
90 ft. |
25 ft. 9 in. |
Separate |
Ground-engaging dual knife |
12-in. (30.48 cm) |
*Models and widths may not be available at the time of publication. Please see your John Deere dealer for details.
Compare our Integrated Tank Air Drills
The 1990 CCS™ is now the N500C Series (Including the N530C, N536C, N540C and N542C): N – no-till opener. 5 – Series. 30 – width. C – Central Commodity System.
| Model | Working Width | Capacity | Spacing | Opener |
|---|---|---|---|---|
|
30 ft. |
100 bu., 120 bu. |
7.5 in., 10 in., 15 in., 20 in. |
ProSeries™ |
|
|
36ft. |
100 bu., 120 bu. |
7.5 in., 10 in., 15 in., 20 in. |
ProSeries™ |
|
|
40ft. |
100 bu., 120 bu. |
7.5 in., 10 in., 15 in., 20 in. |
ProSeries™ |
|
|
42ft. |
100 bu., 120 bu. |
7.5 in., 10 in., 15 in., 20 in. |
ProSeries™ |
Farm Even Better
Maximize the full potential of your field.
Build Your Own
Build and price seeding equipment to fit your needs.
Introducing the Tips Notebook
A compilation of tips, ideas and collective wisdom about how to get all kinds of jobs done around your place. This is where you’ll find the how-do-I-do-that answers you’re looking for, all in one place. It’s loaded with easy-to-understand instructions, videos, and links to product information.
Compare End-Wheel Grain Drills
An easy, mid-priced way to seed into conventional tillage.
· 8 to 13 ft. (2.5 to 4.0 m) working widths
· Drill cereal grains, legumes and forage crops
· Standard hydraulic lift cylinder raises and lowers the openers
· Optional combination seed/fertilizer box available
| Model | Working Width | PTO HP | Hitch |
|---|---|---|---|
|
8 ft. (2.4 m) Wide, 7.5 in. (19.1 cm) row spacing |
42 hp (31.3 kW) minimum |
Pull-Type |
|
|
10 ft. 6 in. (3.2 m) Wide, 6 & 7.5 in. (15.2 & 19.1 cm) row spacings |
42 hp (31.3 kW) minimum |
Pull-Type |
|
|
13 ft. (4.0 m) Wide, 6 & 7.5 in. (15.2, 19.1 cm) row spacings |
42 hp (31.3 kW) minimum |
Pull-Type |
Additional Resources
Shop and Buy
You May Also Be Interested In
1Based on seeding with an 8 primary run air cart and an 24.4 m (80 ft) air seeder. Prescription zones would improve from 24.4 m (80 ft) zones to 3.04 m (10 ft) zones.
2Compared to ProSeries openers installed on MY21 and prior models. Based on internal John Deere testing. Individual results may vary.
3Compared to previous 1910 Air Carts.
4Internal comparison between the N540 with current ProSeries™ opener vs. new ProSeries™ opener.
