John Deere Power Systems 4.5L engines are designed with replaceable cylinder liners for superior cooling, reduced oil breakdown, and reduced ring wear. This means cooler engine components and longer life as compared to cast-in-block designs.
Standard John Deere PowerShift™ Transmission provides smooth, on-the-fly, clutch-free gear shifts.
PowerShift™ transmission provides on-the-go seemingly clutchless gear changes, for the operator.
True four-wheel drive on command. Standard limited-slip mechanical-front-wheel drive delivers superior traction in any ground condition. Engage momentary mechanical-front-wheel drive "on the fly" with the touch of a button on the new loader control.
L-Series pilot towers provide more legroom and additional space for transitioning between loader and backhoe operation. Palm-on-top loader-control grip makes operation even easier with integrated electric clutch disconnect and momentary MFWD.
An additional 10–15-percent increase in craning capacity is activated through Lift Mode at the push of a button on the convenient sealed switch module.
Ride control, front loader hydraulic cylinders act as a shock absorber, smoothing travel over rough terrain.
Same-side, ground-level service points help speed daily checks and fills. Other common-sense features such as quick-change filters, extended service intervals, simple-to-read sight gauges, and easy-access grease zerks help increase uptime and lower daily operating costs.
Machine-security system with touchpad passcode helps prevent unauthorized operation.
Specs & Compare
|Select up to 4 models to compare specifications||
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech Plus 4045HT084|
|Displacement, ltr (Inches³)||4.5 (276)|
|Rated Speed, rpm||2240|
|Engine Output - Net, kW (hp)||110 (148)|
|Transmission Type||Power Shift|
|Service Brake Type||Wet Disc|
|Service Brake Actuation||Hydraulic|
|Max length with std. Stick, mm (ft/in)||8230 (27 ft )|
|Height over std Stick, mm (ft/in)||4450 (14 ft 7 in)|
|Height over ext Stick, mm (ft/in)||4490 (14 ft 9 in)|
|Width over tires, mm (ft/in)||2370 (7 ft 9 in)|
|Wheelbase - 4WD, mm (ft/in)||2550 (8 ft 4 in)|
|Ground Clearance, mm (inches)||356 (14)|
|Width - General Purpose Bucket, mm (ft/in)||2464 (8 ft 1 in)|
|Bucket Rotation - Position 1, Degrees||190|
|Bucket Pin Height - General Purpose, mm (ft/in)||3730 (12 ft 3 in)|
|Dump Height - General Purpose, mm (ft/in)||2890 (9 ft 6 in)|
|Dump Reach - General Purpose, mm (inches)||768 (30.2)|
|Digging Depth - General Purpose, mm (inches)||157 (6.2)|
|Fuel Tank, ltr (gallons (US))||174.1 (46)|
|Hydraulic Tank, ltr (gallons (US))||50.1 (13.2)|
|Rear Axle, ltr (gallons (US))||25 (6.6)|
|4WD Front Axle, ltr (gallons (US))||15 (3.975)|
|Bucket Capacity - Standard General Purpose, m³ (yd³)||1.24 (1.62)|
|Battery Voltage, V||12|
|Bucket Tearout - Non-Extending Dipper, kN (lbf)||84.3 (18959)|
|Stick tearout, kN (lbf)||57.4 (12910)|
|Boom Lift - Maximum Reach - Non-Extending Dipper, kg (lbs)||2321 (5118)|
|Bucket Breakout - General Purpose, kN (lbf)||73.6 (16539)|
|Lift To Full Height - General Purpose Bucket, kg (lbs)||4475 (9866)|
|Pump||Axial Piston Pump|
|Pump Flow, lt/min (gallons (US) / min)||197 (52)|
|Operating Weight, kg (lbs)||11607 (25588)|
|Weight - 4WD, GP, std Stick, kg (lbs)||11607 (25588)|
Features and specifications are based on published information at the time of publication. Features and specifications are subject to change without notice.
