A 20-hp (14.9-kW) V-twin engine has plenty of power and torque to handle tough mulching, mowing, and bagging conditions:
No-tools oil drain valve provides easy access for oil changes.
A Kanzaki® Tuff Torq® hydrostatic transmission gives an infinite choice of speeds and makes changing the direction of travel easy:
Appropriate transmissions are used in each model, depending on rear tire size and tractor performance requirements to ensure excellent performance and reliability:
Easy-to-use cruise control option maintains the tractor's speed for mowing larger areas:
Kanzaki is a trademark of Kanzaki Kokyukoki Manufacturing Company. Tuff Torq is a trademark of Tuff Torq Corporation.
The Edge Cutting System has been trademarked to emphasize the advantages of the John Deere mower deck designs. They give the mower superior convenience, performance, and reliability.
The 42-in. (107-cm) two-spindle, three-in-one mower is constructed of 13 gauge, 0.090 in. (2.3 mm) steel for long life:
The mower deck has a rolled lip to provide greater strength and protection.
The blade-to-spindle design provides a unique mounting system for the mower blade that gives extra safety and convenience.
A cut-and-throw 6.5-bu (229-L) rear bagger is sold separately.
A wash port is provided to make cleaning the underside of the mower deck easy:
The StarLock blade design keeps the blade bolt at the correct torque for easy removal.
Optional blades for difficult mulching or bagging conditions are available.
Spring-assisted, low-effort lift lever simplifies setting and adjusting the mower cut height:
The solid one-piece frame is constructed of 12-gauge, 0.11-in. (3.0-mm) steel:
|Select up to 4 models to compare specifications||
|Displacement||40 cu in.
|Type||Overhead valve, full-pressure lube, oil filter|
|Choke/speed control||One lever|
|Oil drain||No tools|
|Fuel delivery||Pulse pump and carburetor|
|Fuel gauge||Mechanical, viewable from seat|
|Fuel tank location||Rear|
|Fuel fill opening||Center, 2 in.
|Fuel tank capacity||2.4 U.S. gal.
|Charging system||Regulated, 9 amp|
|Engine starter||Bendix type|
|Hourmeter||Yes, with service reminder|
|Headlights||Two standard, incandescent|
|Taillights or reflector||No|
|Rear work lights||No|
|Type||Hydrostatic, 2-wheel drive|
|Control||Two-pedal foot-controlled hydrostatic|
|Oil cooler||Fins and fan on transaxle|
|Oil filter||Yes, internal|
|Forward speed||0-5.5 mph
|Reverse speed||0-3.2 mph
|Frame||Full-length welded steel|
|Weight bracket||Optional rear|
|Front axle||Cast iron front axle, front wheel ball bearings|
|Hood material||JD Loy, UV resistant|
|Fender deck material||Stamped steel|
|Storage||Storage tray with cover|
|Service interval decal||Yes|
|Equipment mounting||CargO Mount? system|
|Type||Sector and pinion with single drag link and tie rod|
|All-wheel steer||Not available on this model|
|Steering wheel||Standard, diameter - 12 in.
|Tilt steering wheel||No|
|Turning radius||18 in.
|Uncut circle radius||25 in.
|Seat back height||15 in.
|Fore-aft adjustment||While seated, 5.5 in.
|Seat suspension||Tilt, two coil springs|
|Type||Lever on fender deck|
|Mower cut height||13 positions, 1-4 in.
|Cut height increments||0.25 in.
|Preset cut height||No|
|Cutting width||42 in.
|Construction||Stamped steel deck shell|
|Mower deck material||Steel, 13 gauge
|Mower wash port||Yes|
|Mower drive system||Manual PTO|
|Mower wheel adjustment||One bolt|
|Mower level adjustment||Easy-level deck|
|Type||Slide under tractor|
|Front draft arms||One spring clip|
|Rear draft arms||Two pins and spring clips|
|Mower wheels rotate||No|
|Drive system||Single belt|
|Meets ANSI standard||Yes|
|Meets OPEI standard||Yes|
|Backup protection||Reverse Implement Option (RIO)|
|Notes||JD Loy hood resists fading, won't rust or dent
Durable primer and powder paint finish
Full-length welded steel frame
|Warranty||2 year/120 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.)|
|Mowers||Standard, 42 in.
|Rear bagger||2-bag, 6.5 bu
|Powered material collection|
|Mulching system||Mulch cover or high-performance plug|
|Front blade||46 in.
|Snow blower||Two-stage, 44 in.
|Rear power take-off (PTO)|
|Sprayer||Tow-behind only, 15 U.S. gal.
Tow-behind only, 25 U.S. gal.
|Spreader||Tow-behind only, 125 lb
|Front bumper||Two-bar styled front bumper|
|Weather protection||Snow cab|
|Rear receiver hitch|
|Bucket holder||Yes, single bucket|
|Grass striping||Lawn striping kit|
|Overall length||68.8 in.
|Width with mower||54.9 in.
|Width with mower (deflector raised for storage)||44.8 in.
|Width without mower|
|Weight||Mower, no fuel, 438 lb
