With horsepower from 50 to 130, the 5 Series Tractors have an option for all your jobs.
Model | Engine HP¹ | PTO HP | Economy PTO | PTO Speed | 2WD or MFWD | Cab or Open Station |
---|---|---|---|---|---|---|
50 hp (37 kW) @ 2100 rpm |
37 hp (27.6 kW) @2100 rpm |
No |
540 at 2100 rpm |
Both |
Open Station |
|
60 hp (45 kW) @2100 rpm |
42.9 hp (32 kW) @2100 rpm |
Yes (Optional on PowrReverser models only) |
540 at 2100 rpm 540E at 1588 rpm |
Both |
Both |
|
67 hp (50 kW) @2100 rpm |
49 hp (36.6 kW) @2100 rpm |
Yes (Optional on PowrReverser models only) |
540 at 2100 rpm 540E at 1588 rpm |
Both |
Both |
|
75 hp (55 kW) @2400 rpm |
57.6 hp (43 kW) @2100 rpm |
Yes (Optional on PowrReverser models only) |
540 at 2100 rpm 540E at 1588 rpm |
Both |
Both |
|
90 hp (67 kW) @2400 rpm |
75 hp (52.2 kW) @2400 rpm |
Yes Standard |
540 at 2400 rpm 540E at 1716 rpm 1000 at 2400 rpm |
MFWD |
Both |
|
100 hp (74 kW) @2400 rpm |
85 hp (63.4 kW) @2400 rpm |
Yes Standard |
540 at 2400 rpm 540E at 1716 rpm 1000 at 2400 rpm |
MFWD |
Both |
1Engine power PS (hp ISO) at max engine power speed (ECE-R120). John Deere Standard RES10080, SAE Standards J1995.
Model | Engine HP¹ | PTO HP | Rated Flow | PTO Speed | 2WD or MFWD | Cab or Open Station |
---|---|---|---|---|---|---|
75 hp (55.1 kW) @2200 rpm |
57.7 hp (43 kW) @2100 rpm |
24.7 gpm (94 I/m) |
540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
Both |
Both |
|
95 hp (70 kW) |
80 hp (58.8 kW) @2100 rpm |
PowrReverser PowrQuad PLUS/ Powr8 |
540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
PowrReverser PowrQuad PLUS/ Powr8 |
PowrReverser PowrQuad PLUS/ Powr8 |
|
105 hp (77 kW) |
90 hp (66.2 kW) |
PowrReverser™: 24.7 gpm (94 l/min) PowrQuad™ PLUS/Powr8™: 25.6 gpm (97 l/min) |
540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
MFWD |
PowrReverser PowrQuad PLUS/ Powr8 |
|
120 hp (88 kW) |
105 hp (77.2 kW) @2100 rpm |
PowrReverser™: 24.7 gpm (94 l/min) PowrQuad™ PLUS/Powr8™: 25.6 gpm (97 l/min) |
540 rpm @ 2100 rpm 540E rpm @ 1645 rpm 1000 rpm @ 2100 rpm |
MFWD |
PowrReverser PowrQuad PLUS/ Powr8 |
|
130 hp (95 kW) |
115 hp (84.5 kW) @2100 rpm |
25.6 gpm (96.9 l/m) |
540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
MFWD |
Cab Only |
1Engine power PS (hp ISO) at max engine power speed (ECE-R120). John Deere Standard RES10080, SAE Standards J1995.
