Spécifications et comparaison
Certifications sur les émissions
| CARB |
|
|
|
|
| Catégorie 1 de l'EPA |
|
|
|
|
| Phase I de l’UE |
|
|
|
|
General engine data
| Model |
3029TF150 |
|
|
|
| Number of cylinders |
3 |
|
|
|
| Displacement-- L (cu in) |
2.9 (177) |
|
|
|
| Bore and Stroke-- mm (in) |
106 x 110 (4.17 x 4.33) |
|
|
|
| Compression Ratio |
17:2:1 |
|
|
|
| Engine Type |
In-line, 4-Cycle |
|
|
|
| Aspiration |
Turbocharged |
|
|
|
| Length - mm (in) |
716 (28.2) |
|
|
|
| Width-- mm (in) |
519 (20.4) |
|
|
|
| Height-- mm (in) |
928 (36.5) |
|
|
|
| Weight, dry - kg (lb) |
328 (723) |
|
|
|
Performance data range
| Intermittent - Rated power/Rated speed |
52-59 kW (70-79 hp) @2500 rpm |
|
|
|
| Intermittent - Peak power |
52-59 kW (70-79 hp) @2500 rpm |
|
|
|
| Intermittent - Peak torque |
239-271 N·m (176-200 ft-lb) @1600-1800 rpm |
|
|
|
| Intermittent - Torque rise |
NA |
|
|
|
