XUV625iCrossover Utility Vehicle
- Advanced Engine System
- Superior Terrain Capability
- Best in Class Ride Quality
- In-store pickup or delivery available
Features
Expand All
Collapse All
Deluxe cargo box (XUV 825i Camo shown)
Tailgate handle
Tailgate lowered to 150 degrees
Integrated handle for manual cargo box tilt
Integrated tie-down point in cargo-box bed
Additional tie-down points (TH 6X4 shown)
Deluxe cargo box converted to flat bed (XUV 825i Shown)
Deluxe cargo box converted to flat bed (XUV 825i Shown)
CAUTION: Carrying extra-long cargo that extends beyond the box can adversely affect stability.
Brake and taillight with protector
Bedmat—protects the steel floor from dents
Cargo box power lift
Cargo box power lift
Variable-speed drive
Side view of CVT intake and clutch on closure (XUV855D shown)
Front differential rocker switch
Rear end shot of transaxle/CV shafts (XUV625i)
XUV front suspension detail
XUV rear suspension detail
617-cu cm (0.022 cu ft) gasoline engine
Extra-durable deluxe cargo box ensures hard-working performance and longevity
Deluxe cargo box (XUV 825i Camo shown)
The deluxe cargo box consists of a 15 percent glass-filled polypropylene composite material that eliminates rust, dents, and reduces noise.
Deluxe cargo box tailgate
Tailgate handle
Tailgate lowered to 150 degrees
The tailgate can be opened or removed for easier cleanout and to carry longer items. The tailgate has been improved, features truck-like performance, and can be operated with one hand.
The standard installed lanyards can also be removed to lower the tailgate to 150 degrees for convenient loading and unloading tasks.
Deluxe cargo box tilt
Integrated handle for manual cargo box tilt
The deluxe cargo box is now easier to latch, unlatch, raise, and lower with the integrated handle design and gas assist.
A prop rod is provided to hold the box in the upright position for operator convenience, as well as limit box pivot travel.
Integrated tie-down points
Integrated tie-down point in cargo-box bed
Additional tie-down points (TH 6X4 shown)
The deluxe cargo box offers integrated tie-down points for increased versatility. Tie-down points are located in the following areas:
- Four corners inside the cargo box bed
- Four points on the load guard directly behind the operator station (A)
- Tie-down bars on either side of the cargo box (B)
- Six points on the underside of the cargo box frame (circled)
Converting deluxe cargo box to a flat bed
Deluxe cargo box converted to flat bed (XUV 825i Shown)
Deluxe cargo box converted to flat bed (XUV 825i Shown)
The deluxe cargo box easily converts to a flat bed. The flatbed configuration allows loading larger cargo.
Specifications
| Length | 1143 mm (45 in.) |
| Width | 1320 mm (52 in.) |
| Depth | 304 mm (11 in.) |
| Volume | 0.46 cu m (16.4 cu ft) |
| Weight capacity | 454 kg (1000 lb) |
| Dump angle | 47 degrees |
CAUTION: Carrying extra-long cargo that extends beyond the box can adversely affect stability.
Optional accessories
Brake and taillight with protector
Bedmat—protects the steel floor from dents
Cargo box power lift
Cargo box power lift
Optional accessories for the deluxe cargo box include:
- Factory-installed brake and taillight with protector
- Factory-installed spray-in liner (not shown)
- Improves skid resistance and surface abrasion protection
- Cargo box bed mat
- Cargo box power lift
Superior terrain capability
The Gator™ XUV Crossover Series Utility Vehicle has a precision-engineered drivetrain system that fully utilizes engine power, optimizing acceleration, hauling, towing, and hill-climbing capabilities. Power is transmitted from the engine through a continuously variable clutch system to the transaxle.
Key elements of the drive system include:
Variable-speed drive
Variable-speed drive
The variable-speed drive consists of two clutches and a drive belt:
- Drive clutch is attached to the engine.
- Driven clutch is attached to the transaxle.
Features include:
- The engine braking system utilizes a tight belt for operation, requiring an idler sleeve on the primary clutch for neutral. The secondary clutch is a new build-on-shaft design that utilizes a cam to tune the acceleration and deceleration of the vehicle. The clutch will stay engaged, providing deceleration until approximately (5 km/h) 3 mph.
- The Continuously Variable Transmission (CVT™) air intake draws in 50 percent more air vs. previous designs to reduce heat and the amount of water ingestion into the CVT system. The system will reduce belt slipping and improve durability.
- A low- and high-speed forward gear offering:
- Low range is 0 km/h to 27 km/h (0 mph to 17 mph), 625i
- Low range is 0 km/h to 43 km/h (0 mph to 27 mph), 825i and 825i S4
- Low range is 0 km/h to 24 km/h (0 mph to 15 mph), 855D and 855D S4
- High range is 0 km/h to 40 km/h (0 mph to 25 mph), 625i
- High range is 0 km/h to 71 km/h (0 mph to 44 mph), 825i and 825i S4
- High range is 0 km/h to 51 km/h (0 mph to 32 mph), 855D and 855D S4
- Ability to creep along slowly to maneuver in tight spaces
- Standard full clutch enclosure with high speed fan provides longer belt and clutch life
- High-ratio clutches with three cam weights for maximum belt clamp load in high torque conditions
- Powertrain reduction ratios:
- The complete reduction ratios range for high gear is (8.6:1 at top speed and 42:1 at initial clutch engagement. This varies between the three vehicles listed above.
- The complete reduction ratios range for low gear is (17.9:1 at top speed and 86.8:1 at initial clutch engagement. This varies between the vehicles listed above.
NOTE: Delivery and torque to the ground depends on tire size which is a function of nominal size and pressure.
How the variable-speed drive works:
- As engine speed increases, the spring-loaded drive clutch is closed by weights being forced out by centrifugal force.
- As the drive clutch closes, the belt rides up to the largest diameter of the drive clutch and forces open the driven clutch.
- With the belt running in the smallest diameter of the driven clutch, the speed being transferred to the transaxle is increased.
- The driven clutch is designed to sense varying loads (inclines, mud, etc.) and constantly adjusts drive speed upward or downward so that engine rpm remains optimal.
Transaxle, mechanical front-wheel drive (MFWD), and constant velocity (CV) shafts
Side view of CVT intake and clutch on closure (XUV855D shown)
Front differential rocker switch
Rear end shot of transaxle/CV shafts (XUV625i)
Operator interface
-
On-demand true four-wheel drive (4WD) system with an auto-locking front differential and dash-mounted electronic rocker switch is best in class; when the rocker switch is in the on (4WD) position, the front differential will automatically lock for extra traction when needed, but when the rocker switch is in the off two-wheel drive (2WD) position, the vehicle will remain in 2WD
-
Provides exceptional traction in challenging conditions
-
Maintains turf-friendly operation in 2WD mode
-
Illuminated for visibility in low light conditions
- Provides exceptional traction in challenging conditions
-
Maintains turf-friendly operation in 2WD mode
-
Illuminated for visibility in low light conditions
-
-
Transaxle
-
Two-speed fully enclosed oil bath transaxle allows for superior pulling ability
-
Cast aluminum design is the most robust in the industry
-
Helical forward and reverse gears are used for quiet operation
-
Rear traction assist (differential lock) is built in and can be engaged on demand
-
Allows locking the rear drive wheels together
-
Provides increased traction in tough spots
-
NOTE: Differential design reduces scuffing of the turf during turns because it allows the inside wheels to turn slower than the outside wheels
-
-
Neutral start safety interlock for engine ignition system
-
Large, sealed bearings are located inside the housing for better protection and durability
-
Contains gear case for transferring power to the MFWD
-
Splined shaft interfaces for maximum torque transfer and durability
-
All drive gears machined from highest grade gear steel
-
Protected by a skid plate
-
-
Mechanical front-wheel drive
-
Electronic design is auto-locking for ease of use
-
Performs like a locking differential when engaged, but like an open differential when cornering
-
Offers positive engagement of both front wheels in forward and reverse as a differential package
-
Automatic engagement on the fly—no shift linkages required
-
-
Protected by a skid plate and frame
-
-
Drive shafts
-
Rear CV shaft diameter measures 27 mm (1.1 in.) and designed for peak engine and braking torque
-
Front CV shaft diameter measures 23.9 mm (0.94 in.) and designed for peak engine torque
Propshaft (transaxle to MFWD shaft) diameter measures 23 mm (0.91 in.) and designed for peak engine torque -
All CV shaft and propshaft joints are maintenance free and protected by exclusive Neoprene boots for durability
-
Dual A-arm front and rear suspension provides a smooth ride over challenging terrain and excellent hauling characteristics
XUV front suspension detail
To complement the most capable frame available in a high-performance utility vehicle, the XUV is equipped with four-wheel independent suspension.
A dual A-arm front and rear suspension provides a smooth ride over challenging terrain and excellent hauling characteristics.
The entire suspension system has been optimized to handle no cargo to maximum cargo without compromising ride quality or vehicle stability.
Dual A-arm front suspension features include:
-
203.2 mm (8 in.) of travel provides ample compression and wheel extension, which keep all four wheels on the ground for superior traction and vehicle control
-
17.5-mm (0.6875-in.) solid anti-roll bar with fully rubber isolated connecting links and pivots for minimal vehicle body roll and quiet operation
-
Heavy-duty nodular cast-iron knuckles to support the strut, constant-velocity (CV) shaft, and wheel
-
Maintenance-free rubber torsional A-arm pivots for long life and quiet operation
-
CV shaft protection from sticks that may puncture the rubber boot
XUV rear suspension detail
Dual A-arm independent rear suspension features include:
-
Unequal length, dual A-arm construction for superior wheel control and travel
-
228.6 mm (9 in.) of total travel provides ample compression and wheel extension, which keep all four wheels on the ground for superior traction, excellent ride quality, and vehicle control
-
Coil over shocks absorb the most demanding terrain
-
A-arms made from square/rectangular tubing reduce weight while remaining rigid
-
Heavy-duty nodular cast-iron uprights support wheel loads with a double row of ball bearings
-
CV driveshaft protection from sticks that may puncture the rubber boot
-
Rear sway bar for lateral stability
Powerful gas engine delivers superb starting, idling, and throttle response
617-cu cm (0.022 cu ft) gasoline engine
The XUV 625i is powered by a 617-cu cm (0.62 L), twin-cylinder, liquid-cooled, four-cycle gasoline engine. It produces 4.5 kgm of torque (32.9 lb-ft) at 2100 rpm. The advanced electronic fuel injection delivers superb starting, idling, and throttle response during operation.
The engine offers the following performance and reliability features:
- Electronic fuel injection for superb performance, altitude adjustment, and cold-weather starting (tested to -28°C/-20°F)
- 22.5 hp* at 4000 rpm
- Electronic ignition is continuously variable for optimum engine power and provides fast, reliable starts
- Exclusive electronic ground-speed governor and throttle body
- Auto compensates by providing more power when going up a hill or through difficult terrain
- Eliminates top-speed degradation from belt wear
- Overhead valve design provides greater efficiency and fuel economy
- Full-pressure lubrication system
- Spin-on oil filter with drain bracket and oil drain valve enable easy servicing
- Dry replaceable single-element air cleaner with remote intake
- See-through coolant recovery tank permits the operator to check the coolant level without having to remove the radiator cap
- Sealed radiator compartment keeps trash and debris on the outside of the grille
- Optional speed-limiter kit allows full power and acceleration with keyed lockout to limit the top speed to 5 mph
Additional details on the electronic governor and throttle body
- The electronic governor system allows the electronic control unit (ECU) to continuously monitor the throttle opening and engine speed, electronically regulating the throttle opening to maintain a constant vehicle speed, even under changing engine-load conditions
- Electronic throttle control (ETC) is an electronic link between the accelerator pedal and the throttle; the ECU determines the required throttle position through other sensors; the system provides input to the fuel injection system
- Benefits of ETC are consistent powertrain characteristics, regardless of engine temperature, altitude, accessory loads, etc.; ETC also dramatically improves the ease with which the driver can execute gear changes and deal with the dramatic torque changes associated with rapid accelerations and decelerations
- Benefits of ETC are consistent powertrain characteristics, regardless of engine temperature, altitude, accessory loads, etc.; ETC also dramatically improves the ease with which the driver can execute gear changes and deal with the dramatic torque changes associated with rapid accelerations and decelerations
* The engine horsepower information is provided by the engine manufacturer to be used for comparison purposes only. The actual operating horsepower will be less.
Evaporative emissions system
Similar to the TX California, the XUV625i has an evaporative emissions system.
The evaporative emissions system reduces the amount of fuel vapors that are vented into the atmosphere.
Utilizing a sealed fuel filler cap, an evaporative canister of activated charcoal and appropriate hoses, the vapors are captured and drawn into the engine to be burned normally, reducing evaporative emissions.
CARB and EPA compliant in the Small Off-Road Emissions (SORE) class.
Specifications
Add Model
| Specifications | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere XUV625i Crossover Utility Vehicle |
Key Specs
| Engine power | ||||
|---|---|---|---|---|
| Maximum traveling speed | ||||
| Cargo box dimensions | ||||
| Cargo box capacity (weight) | ||||
| Towing capacity | ||||
| Front suspension | ||||
| Rear suspension | ||||
| Final drive | ||||
| Four wheel drive | ||||
| Fuel capacity |
Engine
| Type | 4-cycle gas, Electronic Fuel Injection (EFI) | |||
|---|---|---|---|---|
| Displacement | 617 cc | |||
| Power | 22.5 hp 16.8* kW |
|||
| Cooling system | Liquid |
Drivetrain
| Transmission | Continuously Variable Transmission (CVT) with clutch enclosure | |||
|---|---|---|---|---|
| Final drive | Two speed, oil bath | |||
| Four wheel drive | On-demand true four-wheel drive system | |||
| Traction assist | Positive locking, mechanically actuated (hand-operated) | |||
| Descent control | No | |||
| Maximum traveling speed | 0-25 hi forward, 0-17 lo forward, 0-20 reverse mph 0-40 hi forward, 0-27 lo forward, 0-32 reverse km/h |
Suspension
| Front | Fully Independent Dual A-Arm with adjustable coils | |||
|---|---|---|---|---|
| Rear | Fully Independent Dual A-Arm with adjustable coils and sway bar |
Brakes
| Type | Front/rear hydraulic disc with twin piston front calipers | |||
|---|---|---|---|---|
| Park brake | Driveline, internal wet multi-disc, hand operated |
Tires / Wheels
| Front | 26x9-12 Ancla M-T (Aggressive Terrain) or 25x9-12 Terrahawk AT (All Terrain) or 27x9-R14 Maxxis Big Horn Radials (Extreme Terrain) | |||
|---|---|---|---|---|
| Rear | 26x11-12 Ancla M-T (aggressive terrain) or 25x11-12 Terrahawk AT (all terrain) or 27x11-R14 Maxxis Big Horn Radials (Extreme Terrain) |
Dimensions / Capacities
| Wheelbase | 79 in. 2007 mm |
|||
|---|---|---|---|---|
| Dry weight | 1450 lb 657.7 kg |
|||
| Length | 116 in. 2946 mm |
|||
| Width | 62 in. 1571 mm |
|||
| Height | 75 in. 1903 mm |
|||
| Tread centers | 51.2 in. 1300 mm |
|||
| Ground clearance | 11 in. 280 mm |
|||
| Fuel capacity | 27.6 L 7.3 U.S. gal. |
|||
| Cargo box dimensions | 1143 x 304.8 x 1320 mm 45 x 12 x 52 in. |
|||
| Cargo box capacity (weight) | 454 kg 1000 lb |
|||
| Payload capacity | 1400 lb 635 kg |
|||
| Towing capacity | 1500 lb 680 kg |
|||
| Hitch | Standard 2-in. receiver |
Features
| Color | Green/Yellow, Camouflage, Olive and Black | |||
|---|---|---|---|---|
| Power steering | No | |||
| Battery / Alternator / Power port | 340 CCA 25.5 amp @ 3200 rpm, regulated, 306 watts |
|||
| Instrumentation | Digital Display (system diagnostic light, speed, 4WD indicator, fuel level, hour meter, miles, park brake light) | |||
| Storage | 2 Cup Holders, Under Hood, Glovebox | |||
| Seating | Bench (Available Bucket Seats) | |||
| Headlights |
Additional information
| Country of Manufacture | U.S. | |||
|---|---|---|---|---|
| Date collected |
Shop and Buy
Maintenance and Support
You May Also Be Interested In
*Manufacturer's suggested list price at time of posting. Unless otherwise indicated, taxes, freight, setup and delivery not included. Dealers may sell for less. Prices and offers valid in Canada. Prices in Canadian dollars. Equipment, models, features, options, attachments and prices may vary by dealer. John Deere reserves the right to change specifications, model features, design, and price of the products described here without notice. Before operating or riding, always refer to the safety and operating information on the vehicle, and in the Operator’s Manual. Actual vehicle top speed may vary based on belt wear, tire selection, vehicle weight, fuel condition, terrain and other environmental factors. The engine horsepower and torque information are provided by the engine manufacturer to be used for comparison purposes only. Actual operating horsepower and torque will be less. Refer to the engine manufacturer’s website for additional information.
