Simplified routing of the electrical and hydraulic systems improves reliability and eases service. Wiring and hoses are placed for protection against wear and damaging bends.
Combining impressive horsepower and power-to-weight ratio with a constant engine speed, L-Series II Skidders deliver superb responsiveness with maximum efficiency. Superior stability ensures excellent pulling power, especially when climbing hills, navigating adverse terrain, or hauling bigger payloads. Higher-ply tire options available from the factory increase tire strength for carrying heavier loads.
The easy-to-use CVT transmission automatically senses the load and delivers more torque and tractive effort as needed to maintain the desired speed.
New steering sensors control articulation speed when nearing frame-to-frame contact, cushioning impact during full articulation and improving operator comfort.
Optional on the 748L-II, Outboard-Extreme axles are designed with larger components to deliver maximum jobsite durability, along with a heavier weight to boost machine stability.
Specs & Compare
|Select up to 4 models to compare specifications||
|Standard Arch Function||Dual|
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech PSS 6.8L|
|Displacement, ltr (Inches³)||6.8 (415)|
|Engine Output, kW (hp)||196 (263)|
|Engine Torque, Nm (lbf / ft)||1141 (841)|
|Transmission||Continuous Variable Transmission|
|Service Brake Type||Inboard Wet discs|
|Parking Brake Type||Wet multi-disc in Transmission|
|Overall Length, mm (inches)||8384 (330)|
|Height Over Cab, mm (inches)||3365 (132.5)|
|Overall Width, mm (inches)||3239 (127.5)|
|Wheelbase, mm (inches)||3925 (154.5)|
|Dozer Blade Height, mm (inches)||687.6 (27.1)|
|Ground Clearance, mm (inches)||557 (21.9)|
|Dozer Blade Width, mm (inches)||2962.4 (116.6)|
|Dozer Blade - Dig Depth, mm (inches)||359 (14.1)|
|Tong Opening At Tips, mm (inches)||3251 (128)|
|Enclosure Area, m² (ft²)||1.77 (19.1)|
|Steering Articulation Angle, ± °||45|
|Fuel Tank, ltr (gallons (US))||391.8 (103.5)|
|Hydraulic Tank, ltr (gallons (US))||123.6 (32.6)|
|Alternator Output, Amp||150|
|Travel Speed, kph (mph)||24.74 (15.37)|
|Oscillation Point||Front axle|
|Oscillation Angle, ± °||15|
|Rated Line Pull, kN (lbf)||213.5 (47997)|
|Rated Line Speed, m/min (ft/min)||20.1 (66)|
|System Voltage, V||24|
|Operating Weight, kg (lbs)||19713 (43610)|
