Rotating, self-leveling cab turns 290 deg. for an all-around view of boom movements and the jobsite, for safe, efficient log loading.
TimberMatic F-12 control system delivers fine-tuned hydraulics, for effortlessly smooth forwarder functions.
Available with a 40-cm-shorter wheelbase, for better agility in thinnings, without compromising stability or load size.
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech Plus 6068|
|Displacement, ltr (Inches�)||6.8 (414.9)|
|Engine Output, kW (hp)||145 (194)|
|Engine Torque, Nm (lbf / ft)||865 (638)|
|Drive Configuration||8 x 8|
|Std tire size front||26.5 - 20|
|Std tire size rear||26.5 - 20|
|Base Carrier Length, mm (inches)||9820 (386.4)|
|Transport Height, mm (inches)||3870 (152.4)|
|Width, mm (inches)||2700 (106.8)|
|Wheelbase, mm (inches)||4900 (193.2)|
|Ground Clearance, mm (inches)||660 (26)|
|Width - Fixed Bunk, mm (inches)||2700 (106.8)|
|Horizontal Reach, m (ft/in)||7.2 (23 ft 7 in)|
|Load Length, mm (inches)||4500 (177.6)|
|Fuel Tank, ltr (gallons (US))||167 (44)|
|Hydraulic Tank, ltr (gallons (US))||161 (43)|
|Alternator Output, Amp||150|
|Lifting Moment - Standard Crane, kNm (lbf / ft)||102 (75)|
|Load Capacity, tonnes (tons (short))||12 (13.228)|
|Travel Speed, kph (mph)||23 (14.3)|
|Tractive Force, kN (lbf)||160 (35968)|
|System Voltage, V||24|
|Pump Capacity, cm� (Inches�)||140 (9)|
|Operating Weight, kg (lbs)||17130 (37765)|
