SP22 SeriesSoil Pulverizers
- Compression springs
- Cutting teeth for superior soil preparation
- iMatch™ compatible
- Steel roller studded with spikes
Not sold in Québec. Please see your local dealer for other options.
Features
Expand All
Collapse All
Compression springs
Cutting teeth on SP20 Series Soil Pulverizers
Frontier™ soil pulverizers are easy to hook up
Steel rollers provide enhanced precision
Compression springs provide added force
Compression springs
The SP10 Series Soil Pulverizers have two 68-kg (150-lb) compression springs, and the SP20 Series Soil Pulverizers have two 72.6-kg (160-lb) compression springs to keep the roller in contact with the ground and force the spikes into the soil down to 25.4-mm (1-in.) deep.
Cutting teeth for superior soil preparation
Cutting teeth on SP20 Series Soil Pulverizers
The SP20 Series Soil Pulverizers feature a double set of 12.7-mm x 50.8-mm (0.5-in. x 2-in.) bar-type cutting teeth. Their staggered mounting slices the surface every 71.1 mm (2.8 in.) for superior soil preparation.
The teeth are reversible for extra life.
iMatch™ quick-hitch compatible for super-quick connection
Frontier™ soil pulverizers are easy to hook up
The iMatch quick-hitch system converts the tractor's 3-point hitch to fixed hooks for a super-quick connection.
Steel roller studded with spikes to penetrate the toughest surfaces
Steel rollers provide enhanced precision
The steel roller on all SP Series Soil Pulverizers are studded with 9.65-mm x 25.4-mm (0.38-in. x 1-in.) spikes that penetrate the toughest surfaces, breaking down clods and creating a fine finish.
Add an optional second roller with two 36.3-kg (80-lb) compression springs for an even smoother finish.
-
