H480Loader
- Superior strength and visibility
- For heavy-duty chores
- Parking stands are integrated on the loader
Features
Expand All
Collapse All
Single-point hydraulic connection
Operating the hydraulic pressure relief knob
Concealed oil lines through boom arm
Oil lines routed through the boom arm
Oil lines routed through the torque tube
Parking stands
Bucket slightly dumped and down pressure
Parking stand in stored position
Removing parking stand
Bucket slightly dumped - Parking stands installed
Mast pin in the closed position
Mast pin in the open position
Masts rotated forward, then bucket rolled back
Relieving the hydraulic pressure
Disconnect/open single point hydraulic connection
Storing the hydraulic hoses
Tractor ready to be backed away from loader
Backing away from loader
Parked loader
Hydraulic shut-off valve (open position)
Hydraulic shut-off valve (closed position)
False rod cylinder
Electric remote carrier latching system on H340 Loader
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
Single-point hydraulic connection to save time and eliminate oil loss
Single-point hydraulic connection
Operating the hydraulic pressure relief knob
The H480 Loader features a single-point hydraulic connection that also incorporates the connection point for any electrical needs and the ability to relieve hydraulic pressure. In order to disconnect the hydraulic connection between the loader and the tractor, it has always been necessary to relieve the hydraulic system oil pressure. This has sometimes been difficult to accomplish and is also the reason why a coupling system was not offered on some tractors.
Now the ability to relieve the hydraulic oil system pressure is included with the single-point hydraulic connection, which allows for easily disconnecting both hydraulic and electrical lines to the loader from a convenient location with virtually no oil loss.
Concealed oil lines improve appearance and reduce damage
Concealed oil lines through boom arm
Oil lines routed through the boom arm
Oil lines routed through the torque tube
Over time, increased width in tractor hoods have caused issues with available space for running traditional oil lines of a loader along the boom, making them more susceptible to damage.
To improve this situation, the oil lines have been routed through the boom arm and the torque tube, improving line protection and the appearance of the loader.
Loader removal (parking) made easy
Parking stands
John Deere loaders are easily removed and reinstalled on tractors without tools. The parking system allows removing or attaching the loader to the tractor in minutes without the need for tools.
In order to remove or park the loader, apply slight down pressure to the loader boom with the bucket dumped at approximately a 30-degree angle. With the tractor in park, install the parking stands and place the mast pins in the open position.
Removing or parking the loader
Bucket slightly dumped and down pressure
Parking stand in stored position
Removing parking stand
Bucket slightly dumped - Parking stands installed
Mast pin in the closed position
Mast pin in the open position
Utilizing the boom circuit with the tractor in neutral, rotate the mast forward until the mast has rotated past the pin location on the mounting frame by extending the lift cylinder. Now using the bucket circuit, rollback the bucket until the mast is removed from the pocket and will clear the tires.
Masts rotated forward, then bucket rolled back
With the tractor in park, shut the engine off and relieve the hydraulic pressure as indicated for the tractor. Relieve pressure on the single-point hydraulic connection, then disconnect or open the single-point hydraulic connector.
Relieving the hydraulic pressure
Disconnect/open single point hydraulic connection
Store the loader half of the single-point connector. The tractor is now ready to back away from the loader.
Storing the hydraulic hoses
Tractor ready to be backed away from loader
Backing away from loader
Parked loader
Boom lockout for easy service
Hydraulic shut-off valve (open position)
Hydraulic shut-off valve (closed position)
A hydraulic shut-off valve is included with the H-Series Ag Loaders to ensure the loader does not lower suddenly. For example, this allows the boom to be locked out when someone is required to be located under the loader boom for service work on the tractor. It should not be used for extended periods of time unless an appropriate support stand is also utilized.
False rod bucket cylinders improve productivity
False rod cylinder
Fast bucket cycle times are important to dump the load from the bucket as quickly as possible, in order to be as productive as possible, while completing loading operations. The bucket cylinder design can have a major impact on this cycle time, especially for the mechanical self-leveling (MSL) loaders.
Therefore, all MSL M- and H-Series Loaders utilize false rod bucket cylinders. A false rod cylinder has a smaller displacement of oil requirement on the head end of the cylinder, which allows this cylinder to dump much faster than a normal cylinder.
Electric remote carrier latching system saves time and energy
The electric remote carrier latching system provides enhanced productivity and improved operator comfort when changing loader attachments. This time-saving feature allows an operator to unlatch and latch attachments for Global or Global Category 2 Carriers without leaving the operator's station.
Electric remote carrier latching system on H340 Loader
Unlike competitive remote latching systems, the John Deere electric remote carrier latching system utilizes a simple electric actuator instead of third function hydraulics and/or diverter valves for the loader.
Loader suspension system (LSS) for the H480 Loader
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
A feature intended to improve loader productivity, the LSS allows the boom cylinders to float,
reducing the jarring effects loads are prone to over rough terrain.
- An accumulator charged with nitrogen and connected to the head-end lift cylinder hose through a T-fitting provides shock absorption
- The cylinders move in and out to allow the boom to float
- Bales can be transported more efficiently from one end of the field to the other over frozen, hard-packed, or rutted terrain
- Pallets can be moved easily without sustaining cargo damage
- Pallets of seed or fertilizer can be carried across a yard without a bag spilling and creating a costly mess
- Extended life of loader pins and bushings
- Less stress on the tractor axle
- Properly ballasted tractor with LSS has increased stability, creating a smoother ride for the operator
Reasons for turning LSS off include:
- Digging applications- with LSS on, the cylinders retract slightly, losing lifting power
- Holding a grade when blading – with LSS on, it is difficult to hold a constant grade
- Precise pallet and bale handling – with LSS on, the load moves up and down slightly while being positioned
- Parking a loader – with LSS on, when down-pressure is applied, the lift cylinders retract slightly, making it more difficult to park
The loader suspension system is controlled by a switch conveniently located in the operator station so it can be easily reached for activation or deactivation as needed.
Specifications
Add Model
Specifications |
||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere H480 Loader |
Key Specs
| Maximum lift height (A) | 4650 mm 183.1 in. |
|||
|---|---|---|---|---|
| Lift capacity at full height | Measured at pivot (U) 2065 kg 4553 lb |
|||
| Boom breakout force | Measured at pivot (Y) 4793 kgf 10567 lbf |
|||
| Bucket rollback force capacity | At ground-level line (ZZ) 4640 kgf 10229 lbf |
|||
| Clearance at full height - bucket dumped (C) | 3820 mm 150.4 in. |
|||
| Dump angle, degrees (E) | -58.9 degree (angle) | |||
| Rollback angle, degrees (G) | 42 degree (angle) |
Tractor
| Model | 7820/7830 | |||
|---|---|---|---|---|
| Front tire | 380/85R34 | |||
| Rear tire | 480/80R46 | |||
| Front axle configuration | ||||
| Wheelbase | 2860 mm 112.6 in. |
|||
| Pump capacity | 96.1 L/min 25.4 gpm |
|||
| Rated pressure | 195 bar 2828 psi |
Loader
| Base weight | ||||
|---|---|---|---|---|
| Leveling configuration | Mechanical Self Leveling (MSL) | |||
| Bucket used | Materials 2450 mm Materials - 85 in. |
|||
| Bucket weight | 352 kg 776 lb |
|||
| Lift capacity at full height | Measured at pivot (U) 2065 kg 4553 lb Measured at 800 mm ahead of pivot (V) 2240 kg 4938 lb |
|||
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 3420 kg 7540 lb Measured at 800 mm ahead of pivot (X) 3280 kg 7231 lb |
|||
| Boom breakout force | Measured at pivot (Y) 4793 kgf 10567 lbf Measured at 800 mm ahead of pivot (Z) 4395 kgf 9689 lbf |
|||
| Bucket rollback force capacity | At maximum height (VV) 3641 kgf 8027 lbf At 59-in. (1500-mm) lift height (XX) 4599 kgf 10139 lbf At ground-level line (ZZ) 4640 kgf 10229 lbf |
|||
| Dimensions | Maximum lift height (A) 4650 mm 183.1 in. At full height - bucket level(B) 4465 mm 175.8 in. At full height - bucket dumped (C) 3820 mm 150.4 in. |
|||
| Overall length (I+F), ft (m) | 5.6 m 18.7 ft |
|||
| Overall height in carry position (J) | 2.4 m 7.8 ft |
|||
| Digging depth (H) | 150 mm 5.9 in. |
|||
| Reach | At maximum height (D) 820 mm 32.3 in. At ground level - bucket level (F) 2790 mm 109.8 in. |
|||
| Bucket angle | Dump angle, degrees (E) -58.9 degree (angle) Rollback angle, degrees (G) 42 degree (angle) |
|||
| Cycle times | Loader raise, seconds 5 seconds Loader lower, seconds 5.5 seconds Bucket dump, seconds 3.5 seconds Bucket rollback, seconds 4 seconds |
Additional information
| Date collected |
|---|
Accessories and Attachments
Expand All
Collapse All
Five-tine round bale/silage grapple with grille
1850-mm (73-in.) bale grapple bucket
73–in. (1850 mm) grapple bucket BW15358 shown (all one piece
Heavy-duty bucket (2450 mm shown with grapple)
Heavy-duty bucket (2750 mm shown with grapple)
Heavy-duty bucket (shown with grapple)
High-volume bucket 2750 mm (108 in.)
Electric remote carrier latching system on H340 Loader
Hood guard on 7730 MFWD Tractor
Hood guard for large-frame 7030 Tractors
Hood guard on 7R Tractor
Hood guard for 7R folded down
Hood guard for 8R and 8030 Series Tractors
Hood guard shown on 8R Series Tractor
Rear hydraulic setup with third-function valve
Rear auxiliary valve kit (close-up)
Third-function utilizing electrohydraulic valve
Third-function hydraulic hoses
Rear hydraulic setup with third-function valve
Rear auxiliary valve kit (close-up)
Third-function utilizing electrohydraulic valve
Third-function hydraulic hoses
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
Single-point hydraulic connection
Operating the hydraulic pressure relief knob
Stationary fender (H480 shown)
Grapples
Five tine round bale and silage grapple with grille - BW16161
Five-tine round bale/silage grapple with grille
All compatible John Deere Loaders use the same five-tine, pin-on grapple. The advantages of this grapple are:
- The pin-on method puts the least amount of stress possible on the bucket.
- The grapple has a wide stance, making it more difficult to twist.
High-performance operators will choose the five-tine grapple for its increased durability and load-carrying capacity. Advantages include:
- The ability to handle two large round bales instead of one (where loader capacity allows).
- Strong grapple arms allow the bucket capacity to be increased by almost twice the amount of normal bucket capacity in materials such as silage.
The grapple is equipped with twin cylinders to provide excellent clamping force.
NOTE: The center tine of the five-tine grapple is slightly off center to avoid contact with the placement of optional digging teeth.
NOTE: The grapple is not compatible with materials or high-volume buckets.
1850-mm (73-in.) bale grapple bucket
73–in. (1850 mm) grapple bucket BW15358 shown (all one piece
The bale grapple bucket is a complete solution ideal for full loads of silage, handling bales, or cleaning up debris or manure.
Miscellaneous
2450-mm (96-in.) heavy-duty global bucket (Category 2) - BW15903
Heavy-duty bucket (2450 mm shown with grapple)
Heavy-duty bucket (2750 mm shown with grapple)
The heavy-duty buckets for the H480 Loader have holes along the cutting edge where the replaceable and reversible cutting edge can be attached, providing more than twice the wear life for the cutting edge. They also include the brackets for attaching the grapple.
2750-mm (108-in.) heavy-duty global bucket (Category 2) - BW15904
Heavy-duty bucket (shown with grapple)
The heavy-duty buckets for the H480 Loader have holes along the cutting edge where the replaceable and reversible cutting edge can be attached, providing more than twice the wear life for the cutting edge. They also include the brackets for attaching the grapple.
2750-mm (108-in.) high-volume global bucket (Category 2) - BW16004
High-volume bucket 2750 mm (108 in.)
The high-volume bucket is intended for use with lighter-density high-volume materials. The bucket capacity makes this an effective tool for handling snow, wood shavings, and other loose materials. The high-volume bucket for the H480 Loader has holes along the cutting edge where the replaceable and reversible cutting edge can be attached, providing more than twice the wear life for the cutting edge.
Electric Remote Carrier Latching System - BW16991
The electric remote carrier latching system provides enhanced productivity and improved operator comfort when changing loader attachments. This time-saving feature allows an operator to unlatch and latch attachments for Global or Global Category 2 Carriers without leaving the operator's station.
Electric remote carrier latching system on H340 Loader
To watch a video of the remote carrier latching system, click here.
Unlike competitive remote latching systems, the John Deere electric remote carrier latching system utilizes a simple electric actuator instead of third function hydraulics and/or diverter valves for the loader.
Hood guard - BW15629
Hood guard on 7730 MFWD Tractor
Hood guard for large-frame 7030 Tractors
The hood guard's basic function is to:
-
Help protect the tractor grill and hood from falling debris or stationary objects such as a wagon or mixer
-
Allow for lighting at night
Compatibility:
-
Can be used with or without the tractor front weight bracket but not with the actual front weights while using the loader (this would over load the front axle)
-
Cannot be used with a front hitch
It is highly recommended to purchase a front weight bracket when using a loader. The hood guard is designed to be slightly rearward of the front weight bracket. This is so that the front weight bracket is the first point of contact against lower stationary objects.
The features of the hood guard include:
-
High height to better protect the top of the hood and to allow operators to see the top of the hood guard
-
Additional bolted-on front bar to protect the front grille against livestock damage
Hood guard for 7R Series Tractors - BW15922
Hood guard on 7R Tractor
Hood guard for 7R folded down
The hood guard's basic function is to:
- Help protect the tractor grille and hood from falling debris or stationary objects such as a wagon or mixer
- Allow for lighting at night
Compatibility:
- Can be used with or without the tractor front weight bracket but not with the actual front weights while using the loader (this would overload the front axle)
- Cannot be used with a front hitch
It is highly recommended to purchase a front weight bracket when using a loader. The hood guard is designed to be slightly rearward of the front weight bracket. This is so the front weight bracket is the first point of contact against lower stationary objects.
The features of the hood guard include:
- High height to better protect the top of the hood and allow operators to see the top of the hood guard
- Additional bolted-on front bar to protect the front grille against livestock damage
Hood guard for 8R Final Tier 4 Tractors - BW16326
Hood guard for 8R and 8030 Series Tractors
Hood guard shown on 8R Series Tractor
The hood guard is designed to allow for the maximum amount of reach while protecting the hood and grille from falling objects. The hood guard also helps to protect the front of the tractor from impacts with wagons or feed mixers or whatever is being loaded.
The hood guard folds down to allow the hood to open, allowing access to service areas.
When using the tractor without a loader, a maximum of 12 front weights can be used with the hood guard installed on 8R and 8030 Series Tractors.
Hoses and parts (3-function) - BW16272
On 8R, 8030, 8020, 8010, and 8000 Series Tractors, the H480 Loader uses rear tractor valves. There is no dedicated loader valve such as an independent control valve for the loader. The hydraulic hoses are routed from the connection point on the mounting frame to the rear tractor selective control valves (SCVs).
Hose connections to rear on 8R Series Tractors
The loader hydraulic hoses can be connected to three rear SCVs. It is recommended that tractors be ordered with five rear SCVs when utilizing an H480 loader.
Hose connections to rear on 8030 Series Tractors
Rear hydraulic setup with third-function valve
Rear auxiliary valve kit (close-up)
The loader hydraulic hoses can be connected to three rear SCVs or two rear SCVs and a rear auxiliary valve kit to provide the third-function service.
Loader hoses hook into SCVs number 3 and 4. The auxiliary valve kit for third function is shown in the following pictures with couplers attached to the valve. The couplers are not included in the bundle and must be ordered from service parts if desired.
For 8030 Series Tractors (s/n 039999 and below) without 5th SCV, order 1-RE241359 Grapple Valve Kit (grapple valve requires four rear SCVs; if not equipped with four rear SCVs, order 1-RE238579), 1-AR243091 Single Lever Control Kit, 1-RE219046 SCO Control Unit, 1-RE250961 Wiring Harness, and 1-R247855 Software Download (software download available from PDC).
For 8030 Series Tractors (s/n 039999 and below) with 5th SCV, order 1-RE241359 Grapple Valve Kit and 1-AR243091 Single Lever Control Kit.
For 8030 Series Tractors (s/n 040000 and above) without 5th SCV, order 1-RE283389 Grapple Valve Kit and 1-AR243091 Single Lever Control Kit.
For 8030 Series Tractors (s/n 040000 and above) with 5th SCV, order 1-AR243091 Single Lever Control Kit.
Hose connections to rear on 8000, 8010, and 8020 Series Tractors
Third-function utilizing electrohydraulic valve
Third-function hydraulic hoses
The loader hydraulic hoses can be connected to three rear SCVs or two rear SCVs and a rear auxiliary electrohydraulic valve kit to provide the third-function service.
Hydraulic hoses and parts (3-function) - BW15910
On 8R, 8030, 8020, 8010, and 8000 Series Tractors, the H480 Loader uses rear tractor valves. There is no dedicated loader valve such as an independent control valve for the loader. The hydraulic hoses are routed from the connection point on the mounting frame to the rear tractor selective control valves (SCVs).
Hose connections to rear on 8R Series Tractors
The loader hydraulic hoses can be connected to three rear SCVs. It is recommended that tractors be ordered with five rear SCVs when utilizing an H480 loader.
Hose connections to rear on 8030 Series Tractors
Rear hydraulic setup with third-function valve
Rear auxiliary valve kit (close-up)
The loader hydraulic hoses can be connected to three rear SCVs or two rear SCVs and a rear auxiliary valve kit to provide the third-function service.
Loader hoses hook into SCVs number 3 and 4. The auxiliary valve kit for third function is shown in the following pictures with couplers attached to the valve. The couplers are not included in the bundle and must be ordered from service parts if desired.
For 8030 Series Tractors (s/n 039999 and below) without 5th SCV, order 1-RE241359 Grapple Valve Kit (grapple valve requires four rear SCVs; if not equipped with four rear SCVs, order 1-RE238579), 1-AR243091 Single Lever Control Kit, 1-RE219046 SCO Control Unit, 1-RE250961 Wiring Harness, and 1-R247855 Software Download (software download available from PDC).
For 8030 Series Tractors (s/n 039999 and below) with 5th SCV, order 1-RE241359 Grapple Valve Kit and 1-AR243091 Single Lever Control Kit.
For 8030 Series Tractors (s/n 040000 and above) without 5th SCV, order 1-RE283389 Grapple Valve Kit and 1-AR243091 Single Lever Control Kit.
For 8030 Series Tractors (s/n 040000 and above) with 5th SCV, order 1-AR243091 Single Lever Control Kit.
Hose connections to rear on 8000, 8010, and 8020 Series Tractors
Third-function utilizing electrohydraulic valve
Third-function hydraulic hoses
The loader hydraulic hoses can be connected to three rear SCVs or two rear SCVs and a rear auxiliary electrohydraulic valve kit to provide the third-function service.
Large ballast box - BW15852
Large ballast box is available to carry additional ballast for greater tractor stability.
Capacities |
|||
Weight |
Sand (Dry) |
Concrete |
Portland Cement |
BW15852 Large ballast box: |
|||
| Volume | 13.3 ft3 = 377L |
||
Material |
581 kg (1277 lb) |
871 kg (1915 lb) |
1089 kg (2395 lb) |
Empty box |
155 kg (342 lb) |
155 kg (342 lb) |
155 kg (342 lb) |
Total |
736 kg (1619 lb) |
1026 kg (2257 lb) |
1244 kg (2737 lb) |
BW15852 Large ballast box is compatible with Category 2 Quik-Couplers and Category 2 or 3 hitches.
See ''Rear Ballast Requirements'' for proper ballasting of the tractor.
Loader suspension system with operator station on/off Switch for 7R Series Tractors - BW16305
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
A feature intended to improve loader productivity, the LSS allows the boom cylinders to float,
reducing the jarring effects loads are prone to over rough terrain.
- An accumulator charged with nitrogen and connected to the head-end lift cylinder hose through a T-fitting provides shock absorption
- The cylinders move in and out to allow the boom to float
- Bales can be transported more efficiently from one end of the field to the other over frozen, hard-packed, or rutted terrain
- Pallets can be moved easily without sustaining cargo damage
- Pallets of seed or fertilizer can be carried across a yard without a bag spilling and creating a costly mess
- Extended life of loader pins and bushings
- Less stress on the tractor axle
- Properly ballasted tractor with LSS has increased stability, creating a smoother ride for the operator
Reasons for turning LSS off include:
- Digging applications- with LSS on, the cylinders retract slightly, losing lifting power
- Holding a grade when blading – with LSS on, it is difficult to hold a constant grade
- Precise pallet and bale handling – with LSS on, the load moves up and down slightly while being positioned
- Parking a loader – with LSS on, when down-pressure is applied, the lift cylinders retract slightly, making it more difficult to park
The loader suspension system is controlled by a switch conveniently located in the operator station so it can be easily reached for activation or deactivation as needed.
Loader suspension system with operator station on/off switch for 8R Series Tractors - BW15974
Nitrogen-charged accumulator and electric valve
Loader suspension and electric remote carrier latch rocker switch panel
A feature intended to improve loader productivity, the LSS allows the boom cylinders to float,
reducing the jarring effects loads are prone to over rough terrain.
- An accumulator charged with nitrogen and connected to the head-end lift cylinder hose through a T-fitting provides shock absorption
- The cylinders move in and out to allow the boom to float
- Bales can be transported more efficiently from one end of the field to the other over frozen, hard-packed, or rutted terrain
- Pallets can be moved easily without sustaining cargo damage
- Pallets of seed or fertilizer can be carried across a yard without a bag spilling and creating a costly mess
- Extended life of loader pins and bushings
- Less stress on the tractor axle
- Properly ballasted tractor with LSS has increased stability, creating a smoother ride for the operator
Reasons for turning LSS off include:
- Digging applications- with LSS on, the cylinders retract slightly, losing lifting power
- Holding a grade when blading – with LSS on, it is difficult to hold a constant grade
- Precise pallet and bale handling – with LSS on, the load moves up and down slightly while being positioned
- Parking a loader – with LSS on, when down-pressure is applied, the lift cylinders retract slightly, making it more difficult to park
The loader suspension system is controlled by a switch conveniently located in the operator station so it can be easily reached for activation or deactivation as needed.
Single-point hydraulic connection tractor half and grapple mobile half - BW16581
Single-point hydraulic connection
Operating the hydraulic pressure relief knob
The H480 Loader features a single-point hydraulic connection that also incorporates the connection point for any electrical needs and the ability to relieve hydraulic pressure. In order to disconnect the hydraulic connection between the loader and the tractor, it has always been necessary to relieve the hydraulic system oil pressure. This has sometimes been difficult to accomplish and is also the reason why a coupling system was not offered on some tractors.
Now the ability to relieve the hydraulic oil system pressure is included with the single-point hydraulic connection, which allows for easily disconnecting both hydraulic and electrical lines to the loader from a convenient location with virtually no oil loss.
Stationary fenders - BW15928
Stationary fender (H480 shown)
Loader stationary fenders are highly recommended for those operating in conditions where the front axle will be in full oscillation and turn frequently or where tight turns are made while maneuvering through gates or obstacles that will catch tractor axle-mounted fenders.
The loader stationary fenders still provide coverage for debris from the tire, but they do not protrude to become damaged in operation. The fenders can be removed to enable better access for servicing as well.
Shop and Buy
Maintenance and Support
You May Also Be Interested In
Product features are based on published information at the time of publication. Product features are subject to change without notice. Contact your local John Deere dealer for more information.
