Simplified routing of the electrical and hydraulic systems improves reliability and eases service. Wiring and hoses are placed for protection against wear and damaging bends.
The easy-to-use CVT transmission automatically senses the load and delivers more torque and tractive effort as needed to maintain the desired speed.
New steering sensors control articulation speed when nearing frame-to-frame contact, cushioning impact during full articulation and improving operator comfort.
Productive new two-speed 4000 Winch delivers internal gear-ratio changes and line speeds similar to the two-speed 6000 Winch.
Exceptionally low diesel exhaust fluid (DEF) consumption rate reduces the need for DEF compared to some other EPA Final Tier 4/EU Stage V systems.
Specs & Compare
|Select up to 4 models to compare specifications||
|Standard Arch Function||Dual|
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech PSS 6.8L|
|Displacement, ltr (Inches³)||6.8 (415)|
|Engine Output, kW (hp)||177 (237)|
|Engine Torque, Nm (lbf / ft)||1025 (756)|
|Transmission||Continuous Variable Transmission|
|Service Brake Type||Inboard Wet discs|
|Parking Brake Type||Wet multi-disc in Transmission|
|Overall Length, mm (inches)||8129 (320)|
|Height Over Cab, mm (inches)||3365 (132.5)|
|Overall Width, mm (inches)||3233 (127.3)|
|Wheelbase, mm (inches)||3680 (144.8)|
|Dozer Blade Height, mm (inches)||687.6 (27.1)|
|Ground Clearance, mm (inches)||557 (21.9)|
|Dozer Blade Width, mm (inches)||2192 (86.3)|
|Dozer Blade - Dig Depth, mm (inches)||359 (14.1)|
|Tong Opening At Tips, mm (inches)||3226 (127)|
|Enclosure Area, m² (ft²)||1.63 (17.5)|
|Steering Articulation Angle, ± °||45|
|Fuel Tank, ltr (gallons (US))||391.8 (103.5)|
|Hydraulic Tank, ltr (gallons (US))||123.6 (32.6)|
|Alternator Output, Amp||150|
|Travel Speed, kph (mph)||24.74 (15.37)|
|Oscillation Point||Front axle|
|Oscillation Angle, ± °||15|
|Rated Line Pull, kN (lbf)||221 (49696)|
|Rated Line Speed, m/min (ft/min)||27.4 (90)|
|System Voltage, V||24|
|Operating Weight, kg (lbs)||19054 (42159)|
