Final Tier 4 (FT4)/EU Stage IV diesel engine packs plenty of power and torque.
Unique Tri-Cool design resists debris buildup and employs large coolers for standout performance in severe, high-load conditions. Add a reversible fan in high-debris applications for quick core cleanout.
Larger entryways with swing-out doors make it easier to get in, get comfortable, and get on with it. Inside, there’s more productivity-enhancing foot- and legroom.
Three-way switchable controls between EH foot, ISO joystick, or H-pattern joystick modes. Includes switchable accelerator/decelerator with right-side foot pedal when operating in ISO or H-pattern joystick-control mode.
Add the new 90-in. bucket, available for the 332G and watch productivity soar.
Factory-installed performance package offers increased productivity and ease-of-use with the following capabilities:
This option, installed in-factory or in the field, provides cross-slope or roll and mainfall slope or pitch of the machine within the in-cab monitor display.
The vertical-lift boom offers more lift height and reach at the top of the lift path, for more stability and truck-loading ability.
Increased auxiliary hydraulic flow and power enable the 330G and 332G to make the most of an even broader range of attachments.
Swing open the rear door and tilt up the hood for convenient ground-level access to dipsticks, fuel- and fluid-filler necks, and filters.
With the universal Quik-Tatch,™ you can go from compact loader bucket, to forks, to whatever, in just seconds. Each loader model delivers plenty of standard hydraulic power to operate augers, roller levels, trenchers, or power rakes, to list just a few.
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Emission Rating||Tier 4|
|Displacement, ltr (Inches³)||3.1 (186.3)|
|Rated Engine Speed, rpm||2500|
|SAE Net Power, kW (hp)||72 (96.6)|
|SAE Gross Power, kW (hp)||74.6 (100)|
|Max. Gross Torque, Nm (lbf / ft)||395 (291.3)|
|Drive Chain Rating [ANSI]||100 - HD|
|Tire size - Standard||14 x 17.5 - 14 PR Hauler|
|Length - No Bucket, mm (inches)||3100 (122)|
|Length - With Bucket Foundry, mm (inches)||3710 (146)|
|Width - No Bucket, mm (inches)||1990 (78.4)|
|Overall Height, mm (inches)||2190 (86.3)|
|Ground Clearance, mm (inches)||250 (9.7)|
|Wheelbase, mm (inches)||1270 (49.9)|
|Rear Departure Angle, Degrees||29|
|Height to Hinge Pin, mm (inches)||3350 (132)|
|Dump Angle, Degrees||48|
|Dump Height - Maximum Foundry, mm (inches)||2690 (106.1)|
|Reach - Max Dump Height Foundry, mm (inches)||710 (28)|
|Rollback - Ground Level, Degrees||35|
|Fuel Tank, ltr (gallons (US))||96.5 (25.5)|
|Rated Operating Capacity - Optional Counterweight Foundry, kg (lbs)||1703 (3750)|
|Rated Operating Capacity - Foundry, kg (lbs)||1633 (3600)|
|Tipping Load - Foundry, kg (lbs)||3269 (7200)|
|Axle Torque - Maximum, Nm (lbf / ft)||9289 (6830)|
|Speed - Maximum, kph (mph)||19.3 (12)|
|Breakout - Lift Foundry, kN (lbf)||37.8 (8520)|
|Breakout - Bucket Foundry, kN (lbf)||61.8 (13904)|
|Hydraulic Power, kW (hp)||37.29 (50)|
|Hydraulic Power - Option, kW (hp)||61.234 (82.1)|
|Pump Output, lt/min (gallons (US) / min)||95 (25)|
|Pump Flow - Option, lt/min (gallons (US) / min)||156 (41.1)|
|System Pressure, bar (PSI)||237.87 (3450)|
|Operating Weight - Foundry, kg (lbs)||4540 (10000)|
Every John Deere machine comes with a level of comfort through our full machine standard warranty. It promises we’ll fix any defects in materials or workmanship on our compact equipment for two years after delivery or 2,000 hours.*
Features and specifications are based on published information at the time of publication. Features and specifications are subject to change without notice.
* As of June 1, 2018, applies to purchases of new John Deere skid steers, compact track loaders, compact excavators, and compact wheel loaders from John Deere or authorized John Deere dealers. Warranty expires two years after the delivery receipt date or after 2,000 machine hours, whichever occurs first. Offer valid at participating dealers only. Some restrictions may apply. See your dealer for complete details.
